| Model No | HTC10-350 |
| AC Input Specification | 1NAC 220V±10%50/60Hz |
| Output voltage range | DC 0-300V |
| Output current range | DC 0-10A |
| Output power range | 3500W |
| Power supply stability rate | 0.3%+10mV |
| Load Stabilization | less than or equal to0.3%+30mV |
| Ripples and Noises | less than or equal to1%+10mVrms |
| Voltage Display Accuracy | 4-digit display accuracy: ± 1% + 1 word (10% - 100% rated value) Display format 0.00V-99.99V 0-0V-999.9V |
| Current Display Accuracy | 4-digit display accuracy: ± 1% + 1 word (10% - 100% rated value) Display format 0.00A-99.99A 0-0A-999.9A |
| insulation resistance | Input output: ≥ 20m Ω Input housing: ≥ 20m Ω Output housing: ≥ 80m Ω |
| Insulation strength | Input housing: ac1500v, 10mA, 1min Output housing: ac1500v, 10mA, 1min |
| O.V.P | Built in o.v.p protection, protection value is + 5% of rated value |
| O.C.P | Built in o.t.p protection, protection value is 85 ℃± 5% (radiator temperature) |
| Voltage Setting | 10-turn precision potentiometer |
| Current setting | 10-turn precision potentiometer |
| Output polarity | Output Positive+) negative - ) Can be grounded at will |
| Work Conditions | Temperature -10℃-40℃ Humidity10%-85%RH |
| Storage environment | Temperature-20℃-70℃ Humidity 10%-90%RH |
| Product size | W 483mm*L 430cm*H 88cm |
| Heat dissipation mode | Forced ventilation and heat dissipation |
